Design & Detail
There is a moment in the design of any great room when the scale of a fireplace shifts from appropriate to arresting — when the fire becomes not merely part of the composition but its undeniable centrepiece. The Stovax Studio 1 Inset occupies exactly that territory. Larger in aperture than the Studio 500, it introduces a wider, more immersive vista of live flame, a viewing experience that rewards those who have designed their room to breathe and to linger. This is a fire for the room that has been made to be lived in, not merely passed through.
The Studio 1 Wood Inset inherits the full breadth of customisation that defines the Studio inset range. Glass and steel frames offer contemporary clarity; the Profil and Bauhaus systems bring an architectural rigour that complements modern joinery and open-plan living. And for those committed to the most uncompromising aesthetic — where the fire is simply an aperture of warmth and light within a seamless wall — the Edge kit dissolves every visible border, leaving only the flame. Each option is as precisely engineered as the firebox itself, ensuring a finished result that feels entirely resolved.
Eco Design certified and DEFRA approved for Smoke Control Areas, the Studio 1 Inset satisfies the modern demand for responsible performance without diminishing the drama of its flame. As with all Studio configurations, its range of possible dimensions and frame pairings is substantial enough to merit a direct conversation with the Real Flame team, who can help translate a design vision into a precisely specified installation that will remain a defining feature of the home for years to come.
From £2,665.00
Documentation & Specification
Studio Edge Information
| Fire Size | Nominal Heat
Output & Range | Max log lengths | Frame dimensions mm
(wxhxd) Edge | Frame dimensions mm
(wxhxd) Edge ‘Cool Wall’ | Efficiency | Energy Efficiency Class |
| Studio 500 | 5.0kW (1.7-7kW) | 250mm (10”) | 550 x 421* | 550 x 428* | 75.8% | A |
| Studio 1 | 5.0kW (1.7-7kW) | 300mm (12”) | 743 x 421* | 743 x 428* | 77.8% | A |
| Studio 2 | 8.5kW (2.8-11.kW) | 400mm (16”) | 943 x 446* | 943 x 453* | 76.3% | A |
| Studio 3 | 12.6kW (3.8-16kW) | 500mm (20”) | 1330 x 451* | 1330 x 463* | 76.1% | A |
*Dimensions given are those overall visible upon installation. Once installed, Edge kits are flush with the finished wall surface. Edge ‘Cool Wall’ kits are recessed 28mm (Studio 500, 1 & 2) or 13mm (Studio 3) from the finished surface.
Key Facts
| Brand | Stovax |
| Ecodesign Plus | Yes |
| High efficiency | up to 77.8% |
| Wood burning | Yes |
| Boost setting for lighting and refueling | Yes |
| Removable steel and TCL baffles | Yes |
| TCL firebox lining | Yes |
| Radiant heat and convected heat | Yes |
| External air facility | Yes |
| Optional warm air ducting system | Yes |
| Top flue connection (internal Ø) | 153mm (6”) |
| Suitable for Smoke Control Areas* | |
