Design & Detail
The Studio 500 Wood Inset range represents a singular achievement in modern hearth design — a family of inset fires so thoughtfully composed that they function simultaneously as heating appliances and works of architectural art. TheStudio 500 Wood Inset introduces this prestigious lineage at a scale conceived for intimacy: a fire that draws the eye without demanding the entire room, creating a focal point of warmth and contemplation in a range of residential settings. Its clean geometry and confident proportions speak a language of restrained modernism that resonates across diverse design contexts.
Few inset fires can rival the Studio 500 Wood Inset in terms of configuration depth. From the clarity of frameless glass and the precision of polished steel to the architectural vocabulary of the Profil and Bauhaus frame systems, the choice of surround allows for a degree of personalisation that is genuinely extraordinary. For those who prefer radical minimalism, an Edge kit transforms the fire into a seamless aperture in the wall, a pure rectangle of living flame uninterrupted by any visible border. Each configuration is a distinct aesthetic position, and each is executed with the same exacting standard of craft.
Holding Eco Design certification and DEFRA approval for Smoke Control Areas, the Studio 500 Wood Inset upholds the environmental commitments expected of a fire sold in London and beyond. Given the extensive range of models and frame combinations available, Real Flame’s team recommends a personal consultation to determine the precise configuration that will meet the unique requirements of the space. This is a fire worth discussing in detail — because the right installation will be a feature of the home for decades to
From £2,449.00
Documentation & Specification
Studio Edge Information
| Fire Size | Nominal Heat
Output & Range | Max log lengths | Frame dimensions mm
(wxhxd) Edge | Frame dimensions mm
(wxhxd) Edge ‘Cool Wall’ | Efficiency | Energy Efficiency Class |
| Studio 500 | 5.0kW (1.7-7kW) | 250mm (10”) | 550 x 421* | 550 x 428* | 75.8% | A |
| Studio 1 | 5.0kW (1.7-7kW) | 300mm (12”) | 743 x 421* | 743 x 428* | 77.8% | A |
| Studio 2 | 8.5kW (2.8-11.kW) | 400mm (16”) | 943 x 446* | 943 x 453* | 76.3% | A |
| Studio 3 | 12.6kW (3.8-16kW) | 500mm (20”) | 1330 x 451* | 1330 x 463* | 76.1% | A |
*Dimensions given are those overall visible upon installation. Once installed, Edge kits are flush with the finished wall surface. Edge ‘Cool Wall’ kits are recessed 28mm (Studio 500, 1 & 2) or 13mm (Studio 3) from the finished surface.
Key Facts
| Brand | Stovax |
| Ecodesign Plus | Yes |
| High efficiency | up to 77.8% |
| Wood burning | Yes |
| Boost setting for lighting and refueling | Yes |
| Removable steel and TCL baffles | Yes |
| TCL firebox lining | Yes |
| Radiant heat and convected heat | Yes |
| External air facility | Yes |
| Optional warm air ducting system | Yes |
| Top flue connection (internal Ø) | 153mm (6”) |
| Suitable for Smoke Control Areas* | Yes |
* Sizes 500, 1, and 2 only. When fitted with a Smoke Control Kit and used in accordance with the operating instructions.
